HARRIER BOOK 2

TATA MOTORS Ltd.

This document must not be used in any w ay, such as copying and redistributing to third parties, w ithout the consent of author .

SRS / Airbag

ECU – DTC Troubleshooting Guide

Version: 14.0

Date: 14-February-2017

Prepared by:Airbag COC Review &

Approved by:Sanjeev VM

Page: 359 of 549

U0422-81:- Invalid Data Received FromBody Control Module- Invalid serial data received

Overview:

ISO Code

U0422-81

Customer Symptom

N.A.

Fault Effects (On Vehicle)

No effect.

Lamp Status (If Any)

N.A.

Fault Detection Condition

Incorrect or implausible reverse gear data received from

BCM module by RCM (SRS) ECU.

Normal Operating Condition

Error free communication between RCM and Body Control

Module.

Probable Trouble Area

Implausible reverse gear data received from BCM ECU

Healing Condition

Clearing of the functional failures in the BCM

Component Details:-

Airbag ECU: - It is fitted in the floor of central console in the car. The Airbag Electronic Control Unit (ECU) controls the

deployment system to allow an appropriate igniting of the Airbags and belt pre-tensioners to restrain the driver and

passengers.

Preliminary Checks:-

Ensure the proper locking of Airbag ECU wiring harness connectors in the vehicle by the locking sound.

2. Check resistance between diagnostic CAN pin number 6 and 14 in OBD connector. It should be 120 ohm.

3. Check for short conditions between CAN_H-CAN_L, CAN_H-GND, CAN_L-GND, CAN_H-Vbat and

CAN_LVbat. There should not be any short circuit conditions.

4. Check continuity between IPC CAN_H (pin no. 15) vehicle side connector to OBD connector CAN_H (pin no.

6) and CAN_L (pin no. 14) vehicle side connector to OBD connector CAN_L (pin no.14).

5. Read IVN DTCs in IPC in Ignition ON condition.

Trouble Shooting:-
