SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag CoC Review &Approved
by:Sanjeev VM
Page: 10 of 549
Scope
The Scope of the DTC troubleshooting guide is for 4 loop, 6 loop,8 loop,10 loop and 12 loop airbag variants.
Purpose
The purpose of this document is for providing guidelines for DTC troubleshooting.
For each DTC this document contains:
1.Overview
2.Component Details.
3.Preliminary Check
4.Troubleshooting
5.DTC’s confirmation
6.Circuit Schematic diagram
7.Component Location Image
8.Connector Location
9.Connector View & Location
10.Inspection Method
