Pin Details:-
C1
ACTUATOR
Amp no
01355082-1
1
PotentiometerGnd
Potentiometer Ground
Gnd
2
PotentiometerFbSig
Potentiometer feedback
signal
Analog
3
PotentiometerSpply
Potentiometer Supply
Power
4
NC
NC
NC
5
Mot +
Motor signal is + in
CW and Motor signal is -
in CCW
Digital
6
Mot -
Motor signal is - in
CW and Motor signal is
+ in CCW
Digital
Inspection Method: -
1) If there is continuity between the Mode motor drive line and Battery line correct the wiring harness (wiring
harness short to Battery)
