DTC’s confirmation:-
After rectification, , Press mode button from control panel and ensure the following points by using TML diagnostic
tool before handing over to customer.
a)
Physical check of Mode parameters change when requested.
b)
Read ECU parameters,
Air Distribution Drive Motor A Output
which should be requested values.
Component Location & Image:-
HVAC kit
Connector View & Information: -
