DTC’s confirmation:-

After rectification, Rotate temperature Knob from control Panel and ensure the following points by referring temperature

parameters using TML diagnostic tool before handing over to customer.

a) Physical check of temperature change when requested.

b) Read ECU parameters

Vehicle Interior Temperature Internal

Circuit Schematic Diagram:-

“Refer the circuit schematics from the tool”

Component Location & Image:-

Connector Location: -

CCM Panel

Connector View & Information: -

Inspection Method: -
