P2453-00: Particulate Filter Pressure Sensor "A" Circuit Range/Performance: Fault check for the pressure sensor

plausibility.

Overview:

DTC Description (User Friendly)

Particulate Filter Pressure Sensor "A" Circuit

Range/Performance: Fault check for the pressure sensor

plausibility.

ECU Pin Number

K042, K016, K015

Customer Symptom

MIL OFF, CEL OFF

Fault Effects (On Vehicle)

Lamp Status (If Any)

Fault Detection Condition (Root cause)

The Cold Condition is recognized, and either the adapted

raw pressure value is above the tolerance limit 18 hPa or the

absolute difference between the upstream pressure and

environmental pressure is greater than the tolerance limit 40

hPa with no error in environmental pressure.

Normal Operating Condition

Proper wire harness between particulate filter differential

pressure sensor.

Probable Trouble Area

Wire harness between particulate filter differential pressure

sensor.

Healing Condition

Rectify the error Clear through diagnostic tool.

Ignition OFF & ON

Component Details:

Particulate filter, differential pressure sensor is mainly used to monitor the soot loading of a particulate filter on a diesel

engine or gas turbine.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above

Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.

3. Check for Damage in EMS ECU connector / Particulate filter differential pressure sensor.

4. Check for any back out of pins at EMS ECU connector / particulate filter differential pressure sensor.

5. Check for any damage of pins at EMS ECU connector / Particulate filter differential pressure sensor.
