Q501 4 Cylinder MT Application
DTC Troubleshooting Data
Version: 0.1
Date: 21-Sep-2018
Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta
Checked By: Yogesh Jadhav
Approved By: Satish Kumar P
Page: 342 of 1052
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Circuit Schematic:
EMS ECU
Differential Pressure Sensor Signal
Differential Pressure Sensor Ground
Differential Pressure Sensor Supply
K42
K16
K15
Particle
Filter
Differential
Pressure
Sensor
01
03
02
Component Location & Image:-
NA
Connector View & Information: -
