Vehicle Platform: OSPREY / AMP
ECU Name: PEPS
DTC Troubleshooting Data
Version: 1.2
Date: 29 Mar 2017
Author:
Rajasekhara Reddy
Page: 23 of 369
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:-
DTC’s confirmation:-
After rectification, ensure the following points before handing over the system to the customer
1. Battery Voltage is between 9 to 16V.
2. Replacement of ECU.
3. Drive the vehicle on road and check the assistance.
Circuit Schematic Diagram:-
N/A
Component Location & Image:-
N/A
Reset the ECU
(Remove the
power plug from ECU and
reconnect after about 5 minutes
)
Yes
No
Is
DTC still
present?
Stop
Replace
the ECU.
Is DTC
Present?
Yes
No
Stop
. Connect the TML Diagnostic Tool
1
.
2.
Turn the Ignition ON
3. Check the status of DTC’s (Memorized/Current
)
. Record the DTC & Clear
4
. Turn Ignition OFF & ON
5
. Verify If
6
P062F – 00
is present
