U0216 - 08:- Lost Communication With Steering Angle Sensor Module

Overview:

ISO Code

U0216 – 08

Customer Symptom

Warning Light Displayed

Fault Effects (On Vehicle)

ABS & EBD – Available, ESP – Not available

Lamp Status (If Any)

ABS – OFF, EBD – OFF, ESP – ON

Fault Detection Condition

1. SAS connector is not connected properly or disconnected

from its location.

2. CAN wire from SAS connector side are disconnected

3. SAS VCC line fuse blown/disconnected.

4. CAN_H, CAN_L or both lines of SAS are open circuit

Normal Operating Condition

SAS communicates properly with TML diagnostic Tool.

Probable Trouble Area

1. SAS connector / SAS fuse.

2. CAN lines of SAS

Healing Condition

1. SAS is connected and no wiring harness issues from SAS

side

2. CAN_H, CAN_L or both lines of SAS are connected

properly

Preliminary Check:

Check resistance in Diagnostic CAN pin no. 6 and 14. It should be 120 Ω.

Check for short conditions between CAN_H (pin no. 26)-CAN_L (pin no. 14), CAN_H (pin no. 26)-GND (pin no. 13),

CAN_L (pin no. 14)-GND (pin no. 13), CAN_H (pin no. 26)-Vbatt (pin no. 1) and CAN_L (pin no. 14)-GND (pin no. 13).

There should not be any short circuit conditions.

Check continuity between IPC CAN_H (pin no. 8) vehicle side connector to OBD connector CAN_H (pin no. 6) and

CAN_L (pin no. 7) vehicle side connector to ODB connector (pin no.14)

Read IVN DTCs in ABS/ESP in IGN ON condition

Note: After rectification please give Ignition latch to heal the DTC.
