Trouble Shooting:
START
1. Turn OFF ignition
2. Wait for 5 seconds
3. Turn ON ignition
4. Connect the diagnostics tool and Read Logged DTCs
Is U0216 – 08
logged in
current state?
Do necessary repairs in the wiring harness.
1. Check if VCC (Pin 4) and Ground (Pin 3) of SAS
is properly connected
2. Check for any blown/disconnected fuse at VCC
line of SAS connector
Is continuity
there?
1. Check for continuity between
SAS CAN_H (Pin 2) to IPC CAN_H (Pin 5) & SAS
CAN_L (Pin 1) to IPC CAN_L (Pin 4) in vehicle
wiring side connector
Do necessary repairs in the wiring harness.
Clear DTC
STOP
Y
Y
N (In History)
N
