4.15

Reset driven distance max Th2O warning lamp ON

Substitution Type:

FUNCTION

Pre-Conditions:

1. ECU should be in Extended Diagnostic Session

2. Ignition ON (T15_st = 1)

3. Engine not running (NMotV = 0)

4. Gear in neutral position

Procedure To Be Followed:

Step 1:

Below Routine to be executed

“Temperature warning lamp ON driven counter reset ($ 02 16)”

Routine Execution Detail:

Refer Section 4.10 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224

A1724_5June2017_V0.2’ document

[

Note:

Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
