4.14

Throttle Valve Actuator

Substitution Type:

COMPONENT

Pre-Conditions:

1. ECU should be in Extended Diagnostic Session

2. Ignition ON (T15_st = 1)

3. Engine not running (NMotV = 0)

4. Gear in neutral position

Procedure To Be Followed:

Step 1: Below Routine to be executed

“TVA DC Motor Test”

Routine Execution Detail:

Refer Section 4.11 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224

A1724_5June2017_V0.2’ document
