4.13

EGR high pressure DC Motor

Description:

- See

Figure 1

: ECU Substitution Flow chart for more details

Substitution Type:

COMPONENT

Pre-Conditions:

1. ECU should be in Extended Diagnostic Session

2. Ignition ON (T15_st = 1)

3. Engine not running (NMotV = 0)

4. Gear in neutral position

Procedure To Be Followed:

Step 1:

Below Routine to be executed

“EGR high pressure offset reset and activation of the learning ($ 02 0F)”

Routine Execution Detail:

Refer Section 4.5 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224

A1724_5June2017_V0.2’ document

Step 2: Below Routine to be executed

“EGR high pressure DC Motor Test”

Routine Execution Detail:

Refer Section 4.7 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224

A1724_5June2017_V0.2’ document

[

Note:

Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
