DTC’s confirmation:
After rectification, ensure the following points using TML diagnostic tool before handing over to customer.
a) Check whether PEPS ECU is communicating with diagnostic Tool or not.
b) DTC should not be present in ECU memory.
Circuit Schematic Diagram:
YES
No
U1315-08 Loss of communication with PEPS
Start
Read IVN DTC in ESCL
If MTO logged against PEPS
in current state?
Check connectivity with PEPS CAN_H to IPC CAN_H (pin no.6) and
PEPS CAN_L to IPC CAN_L (pin no.5) in vehicle wiring side
connector
Repair the wiring
harness
Check battery and ground of PEPS is properly connected or not.
Also check fuse blown.
Do necessary repair in the harness
Clear DTC
Stop
Is continuity
there?
