HARRIER BOOK 2

Vehicle Platform: OSPREY

ECU Name: Hella Body Control Module (BCM) DTC

Troubleshooting Data

Version: 1.4

Date: 15 May 2018

Author: Body CoC

Page: 835 of 855

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

DTC’s confirmation:-

After rectification, ensure the following points before handing over the system to the customer

4) Battery Voltage is between 9 to 16V.

5) Replacement of Sensor.

6) Drive the vehicle on road and check the assistance.

Circuit Schematic

Diagram:-N.A

Component Location & Image:- N.A.

Connector Location: - N.A.

Connector View & Information: - N.A

Note: Above Image is for Indicative purpose only it will be updated once original image is available.

Inspection Method: -N.A.
