B2264 - 17:- RLS Over Voltage error- circuit voltage above threshold
Overview:
ISO Code
B2264 - 17
Customer Symptom
RLS will probably not function or will function
intermittently or partially
Fault Effects (On Vehicle)
Cannot determine scope without knowledge of power
line applicability
Lamp Status (If Any)
None
Fault Detection Condition
If Battery(supply) voltage greater than 16V
Alternator voltage o/p is greater than 14.5V.
Normal Operating Condition
Normal operating range:
ECU will be awake from 9V to 16 V.
Full assistance is b/w 11.5 to 16 volts.
Reduced assistance is b/w 9 to 11.5 V
Probable Trouble Area
Vehicle electrical fault
Healing Condition
N.A.
Component Details: N.A.
Preliminary Checks:
1. Voltage at the battery terminals should be greater than 11.5V.
2. RLS power supply connector should have greater than 11.5V for full assistance.
3. Check battery cable and RLS connector terminals for damage.
4. Check RLS for pin bend/damage.
