2893 / 4910
Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.4
Date: 15 May 2018
Author: Body CoC
Page: 813 of 855
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:-
Start
Turn IGN OFF – ON and wait for 5 seconds
Clear DTCs from BCM ECU
Turn IGN OFF – ON and Start the Engine.
Wait for 5 seconds.
Read DTCs from BCM ECU
Is U1019 - 62 DTC
present
Yes
Connect the vehicle battery, BCM, and
components, if disconnected. Measure Battery
Voltage
Is battery voltage in
range (9V to 16V)
Yes
Stop
No
Charge the battery and/or replace battery
No
B
A
U1019 - 62: Passive Start Stop Mode- Signal Compare Failure
