DTC’s confirmation:-
After rectification, ensure the following points using TML diagnostic tool before handing over to customer.
a) Check whether Power Steering Control Module ECU is communicating with diagnostic Tool or not.
b) DTC should not be present in ECU memory.
Circuit Schematic Diagram:- N.A.
Component Location & Image:- N.A
Connector Location: N.A
Power Steering Control Module Pin assignment:-
CHAMBER A
Pin No.
Pin Name
Description
x
CAN_H
CAN High
x
CAN_L
CAN Low
x
A_GND
Common Switch GND
x
Vbat
Supply Voltage Battery
x
GND
Power GND
Note : Pin no. will be updated once details are available.
Connector View & Information: -
IPC ECU side connector diagram
Note: Above Image is for Indicative purpose only it will be updated once original image is available.
Inspection Method: - N.A.
