Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.4
Date: 15 May 2018
Author: Body CoC
Page: 791 of 855
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
B161A – 23: Internal Unlock Switch– Signal Stuck Low
Overview:
ISO Code
B161A – 23
Customer Symptom
Internal Unlock switch does not operate
Fault Effects (On Vehicle)
Internal Unlock switch does not operate
Lamp Status (If Any)
N.A.
Fault Detection Condition
This fault gets logged by BCM; if signal stuck low
condition is detected for Internal Unlock switch.
Normal Operating Condition
If the vehicle is Internally locked and Internal unlock
switch is press then BCM shall immediately unlock the
door.
Probable Trouble Area
6. BCM connector Fault.
7. Internal Unlock switch input wire Short to ground
from cockpit wiring harness.
8. Switch damaged or stuck
9. BCM ECU fault.
Healing Condition
3. Ignition OFF
ON
4. Clear DTC Command
Component Details:
Interior lock/Unlock switch is used for central door lock/unlock function. If vehicle is internally locked
and user press Internal Unlock switchthen BCM shall operate the central door lock and unlock relays to
unlock the door.
Preliminary Checks:
3. Check Battery Voltage (12.5 V & above)
4. Check ECU pins for oxidation, bending & damage.
