Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.4
Date: 15 May 2018
Author: Body CoC
Page: 786 of 855
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Connector View & Information: -
PEPS ECU side Connector diagram:
\
Note: Above Image is for Indicative purpose only it will be updated once original image is available.
ECU Pin assignment:-
Description
ECU pin
CAN_H chassis
x
CAN_L chassis
x
Battery
x
Ignition input
x
Battery ground
x
Note: Pin no. will be updated once details are available.
Inspection Method: -N.A
