HARRIER BOOK 2

Vehicle Platform: OSPREY

ECU Name: Hella Body Control Module (BCM) DTC

Troubleshooting Data

Version: 1.4

Date: 15 May 2018

Author: Body CoC

Page: 575 of 855

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

DTC’s confirmation:-

After rectification, ensure the following points by using TML diagnostic tool before handing over to customer.

a) Run Input Switch Test routine, operate switches manually for rear wiper and check, DTC B223E – 12 is not

returned with the Routine results.

Circuit Schematic Diagram:-

Note:

For detailed information please refer latest BCM wiring harness schematic.

Connector View & Information: -

Please refer respective BCM Drawing for BCM connector PIN details.

Inspection Method: -
