DTC’s confirmation:-
After rectification, ensure the following points by using TML diagnostic tool before handing over to customer.
a) Run Input Switch Test routine, operate switches manually and check, DTC B220C – 11 is not returned
with the Routine results.
Circuit Schematic Diagram:-
Note:
For detailed information please refer latest BCM wiring harness schematic.
Connector View & Information: -
Please refer respective BCM Drawing for BCM connector PIN details.
Combi Switch(Wiper Control) ECU side connector diagram and front view with pin details
Inspection Method: -
NA
