Wiper & Washer (WW) DTCs
B220C - 11: Front Washer Switch - Circuit Short to Ground
Overview:
ISO Code (DTC Code)
B220C - 11
Customer Symptom
Front washer ON for washer act time.
Fault Effects (On Vehicle)
1. Front washer On continuously
2. Front wiper as washer functionality shall occur
Lamp Status (If Any)
NA
Fault Detection Condition
This fault will be logged after the input switch test
routine execution. User has to operate the switch
manually during routine. If short to ground fault is
detected for Front wash switch then this DTC will be
returned with the Routine results.
Normal Operating Condition
There should not be any fault returned by routine
Probable Trouble Area
1. BCM connector Fault
2. Cockpit wiring harness short to ground
3. Front switch damaged or stuck
4. Combi switch connector fault.
5. BCM ECU fault
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Front washer switch is part of combination stalk switch and interfaced to the BCM. If the IGN is on and
if user put the combi switch to Front Washer position, Front washer pump will turn ON.
Preliminary Checks:
1. Check Battery Voltage (9V-16V)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
