1. Disconnect Ignition switch
2. Check Continuity Between BCM side connector pin
[C1-21]
with BCM Battery Ground
[C1-34/ C1-47]
Continuity Found?
Correct Wiring harness
(Short To Ground)
YES
NO
1. Remove Ignition switch mating connector.
2. Check continuity of Ignition switch contact
[C1- 21]
with BCM battery
[C3-2]
Continuity Found?
YES
NO
1. Ignition switch faulty.
2. Replace Ignition switch
BCM ECU Faulty
Replace BCM ECU
A
B
DTC’s confirmation:-
After rectification, ensure the following points by using TML diagnostic tool before handing over to customer.
Check DTC U100E - 11 is not logged
Circuit Schematic Diagram:-
Note:
For detailed information please refer latest BCM wiring harness schematic
Connector View & Information: -
Please refer respective BCM Drawing for BCM connector PIN details.
Inspection Method: -
NA
