1. Disengage Reverse Gear
2. Check Continuty Between BCM side connector pin [C1-39]
with Vehicle Ground
[C1-34/ C1-47]
Continuity Found?
Correct Wiring harness
(Short To Ground)
YES
NO
Check Continuity Between BCM side connector pin [C1-39] with
Reverse Gear switch contact
Continuity
Found?
Correct Wiring harness
(Open Circuit)
YES
NO
1. Remove Gear selection switch mating connector.
2. check continuity of reverse gear switch contact with battery
Continuity
Found?
Correct Reverse gear side wiring harness[
location TBD] (Open Circuit)
1. Reconnect Gear selection switch mating connector.
2. Engage reverse gear
3. Check continuity between reverse gear contact at BCM side
with battery
YES
NO
Continuity Found?
YES
NO
1. Gear selection switch faulty.
2. Replace Reverse Gear selection switch
BCM ECU Faulty
Replace BCM ECU
A
B
B2503 -11: Reverse Gear Selection Switch - circuit short to ground/ open circuit
