Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.4
Date: 15 May 2018
Author: Body CoC
Page: 116 of 855
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
DTC’s confirmation:-
After rectification, ensure the following points by using TML diagnostic tool before handing over to customer.
a)
Run Input Switch Test routine, operate switches manually and check, DTC B2236 –12 is not returned
with the Routine results.
Note:
For detailed information please refer latest BCM wiring harness schematic.
Connector View & Information: -
Please refer respective BCM Drawing for BCM connector PIN details.
Please refer combiswitch drawing for combiswitch connector PIN details
Inspection Method: -
NA
