B2213 - 12: Front Wiper Park Position Signal - Circuit short to Battery or Open Circuit
Overview:
ISO Code
B2213 - 12
Customer Symptom
Front and rear wash/wipe may not function correctly
Fault Effects (On Vehicle)
Front and rear wash/wipe may not function correctly
Lamp Status (If Any)
NA
Fault Detection Condition
This fault will be logged after the input switch test routine
execution. User has to operate the switch manually during
routine. If short to battery or open circuit fault is detected for
front wiper park position signal then this DTC will be returned
with the Routine results.
Normal Operating Condition
There should not be any fault returned by routine
Probable Trouble Area
1. BCM connector Fault
2. Cockpit harness Short to battery or open
circuit
3. BCM ECU fault
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Front wiper Park Position Signal part of front wiper motor and interfaced to the BCM as a feedback input. If the
IGN is on and if user put the combi switch to front wiper on position, front wiper park position signal gives a
feedback to BCM about the in park and out of park of the front wiper.
Preliminary Checks:
1. Check Battery Voltage (12.5 V & above)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
