Vehicle Platform: Tiago,Tigor & Osprey
ECU Name: Hella Body Control Module (BCM)
DTC Troubleshooting Data
Version: 2.0
Date: 22-10-2018
Author: Parag K
Page: 574 of 737
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
1. Remove Front wiper mating connector
2. Perform visual check of connectors for pin bend or damaged etc.
Connector
Faulty?
Correct Connector fault
(Terminal Bend)
BCM ECU Faluty
Replace BCM ECU
YES
NO
Check if Front wiper park position wire [wiring harness
side] is shorted to ground
[pin details TBD].
Park Switch
Faulty?
1.Remove all BCM connectors
2.Take out Front wiper Park position wire
[C1-18]
from BCM
connector
3.Reconnect all connectors
4.Check if Front wiper Park position is proper.
Front wiper On and Park
input proper?
Reconnect all connectors firmly
YES
NO
YES
NO
A
B
B2213 -11: Front Wiper Park position signal - circuit short to ground
Replace Front wiper motor
assembly
