1.Remove Front wiper motor mating connector
2. Check continuity between BCM harness side connector pin
[C1-
18]
and Front wiper Park position contact at front wiper motor
mating connector
[pin details TBD].
Open Circuit?
Perform the visual check of connectors for pin bend or damaged etc.
Is connector
faulty?
Check continuity at Front wiper park positioncontact
[ pin details
TBD]
with ground
[ pin details TBD]
Continuity found?
BCM ECU Faulty
Correct wiring harness
(Open Circuit)
YES
NO
Correct connector fault
(Terminal Bend)
Correct connector fault Front wiper
motor mating connector
(Open Circuit)
YES
NO
YES
NO
Replace BCM ECU
1. Connect Front wiper motor mating connector
2. check continuity between Front wiper park position
contact[ pin details TBD] with ground [ pin details TBD]
YES
Park input fault. Replace
Front wiper motor
NO
A
B
B2213 -12: Front wiper park position signal - circuit short to Battery
Continuity found?
