HARRIER BOOK 2

Vehicle Platform: Tiago,Tigor & Osprey

ECU Name: Hella Body Control Module (BCM)

DTC Troubleshooting Data

Version: 2.0

Date: 22-10-2018

Author: Parag K

Page: 31 of 737

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

DTC’s confirmation:-

After rectification, ensure the following points using TML diagnostic tool before handing over to customer.

a) DTC should not be present in ECU memory.

Circuit Schematic

Diagram:-N.A

Component Location & Image:- N.A

Connector Location: N.A

Connector View & Information: - N.A

Inspection Method: - N.A

IPC ECU side connector diagram

ECU Side Connector:
