TML HARRIER Infotainment DTC Troubleshooting guide
Version: 0.3 Draft
Date: 17-Aug-18
Author:
Vijaya Bhaskar
B/Pritam Bansod
Page: 107 of 109
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Appendix
Sr.
TML Displayed
DTC Code
DTC Description
Page No.
Display Status
(Mask Status)
1
B1C01-13
AM/FM Antenna Signal Input Open Circuit
8
No
2
B1C33-2A
Hard Switch (Push Button/Rotary Knobs) - signal
stuck in range
12
No
3
B1C0E-13
Microphone Signal Input - circuit open
16
No
4
B1C0A-13
Left Rear Speaker Assembly Output Power / Left
Rear Speaker Assembly Input Signal 1 - circuit open
20
No
5
B1C0B-13
Right Rear Speaker Assembly Output Power / Right
Rear Speaker Assembly Input Signal 1 - circuit open
24
No
6
B1C08-13
Left Front Speaker Assembly Output Power / Left
Front Speaker Assembly Input Signal 1 - circuit open
28
No
7
B1C09-13
Right Front Speaker Assembly Output Power / Right
Front Speaker Assembly Input Signal 1 - circuit open
32
No
8
B1C4E-13
Right Rear Tweeter Assembly Output Power / Right
Rear Tweeter Assembly Input Signal - circuit open
36
No
9
B1C4F-13
Right Front Tweeter Assembly Output Power / Right
Front Tweeter Assembly Input Signal - circuit open
40
No
10
B1C50-13
Left Front Tweeter Assembly Output Power / Left
Front Tweeter Assembly Input Signal - circuit open
44
No
11
B1C51-13
Left Rear Tweeter Assembly Output Power / Left
Front Tweeter Assembly Input Signal - circuit open
48
No
12
B1C20-2A
Steering Wheel control Signal Input – Stuck in Range
52
No
