Vehicle Platform: Tiago,Tigor & Osprey
ECU Name: Hella Body Control Module (BCM)
DTC Troubleshooting Data
Version: 2.0
Date: 22-10-2018
Author: Parag K
Page: 2 of 737
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Change History
Ver.
Change details
1.0
First Release –
DTC related information, Flowcharts for all
features applicable added.
1.1 · -Updated the masking table.
· -Removed the ABS ECU related DTCs (U1309-08, U1609-81).
· -Removed the HVAC ECU related DTCs (U0164-08, U0164-87,
U0424-81).
· -Removed Day time running lamp (DRL) related DTCs.
· -Removed Rear Fog Lamp related DTCs. Input and output both.
- -Removed Door Second Stage UnLock/ Door UnLock control
others Relay
related DTC’s.
1.2
-Masking status of following DTCs are set as masked in DTC
MASKING list.
U0100-08 – lost communication with ECM – message time out
failure .
U0100-87 – lost communication with ECM – missing message
failure
U0151-87 - lost communication with Restrains control module
U0155-87 - lost communication with IPC – bb (U0155-87)
U0167-08
Lost Communication with Vehicle Immobilizer
Control Module VICM Message Time Out Failure (U0167-08)
U3000 - 08 Control Module Bus Signal / Message Failure (
U3000 - 08)
U0167-87 Lost Communication with Vehicle Immobilizer
Control Module VICM Missing Message Failure ( U0167-87 )
-Removed the “display status” word from the heading of last
column of DTC MASKING list
1.3
DTCs mapped with page numbers.
1.4
- DTCs mapped with page numbers.
- Updated header version number.
1.5
Vehicle Platform name renamed to TIAGO from Kite-4.
1.6
B1630 – 62 is marked as mask for Tiago XE (O) and KITE 5 XE &
XE (O) variants. Note added after appendix.
