13
B1C20-13
Steering Wheel Control Input Signal - circuit open
56
No
14
B1C04-13
GPS Signal - circuit open
61
No
15
B1C4B-13
Infotainment Display LVDS connector - circuit open
65
No
16
B1C52 -13
IC Display-LVDS connector - circuit open
69
No
17
B1C4D-08
Button Panel LIN - Bus Signal / Message Failures
73
No
18
U0028-13
Vehicle Communication Bus A - open circuit
77
No
19
U0028-88
Vehicle Communication Bus A - Bus off
79
No
20
U0155-08
Lost Communication With Instrument Panel Cluster
(IPC) Control Module - Bus Signal / Message Failure
81
Yes
21
U0140-08
Lost Communication with Body Control Module -
Bus Signal / Message Failures
86
Yes
22
U0159-08
Lost Communication with Parking Assist Control
Module "A" - Bus Signal / Message Failures
93
Yes
23
U0164-08
Lost Communication with HVAC Control Module -
Bus Signal / Message Failures
98
Yes
24
U045A-81
Invalid Data Received from Parking Assist Control
Module “A”
103
Yes
