Q501 4 Cylinder MT Application
DTC Troubleshooting Data
Version: 0.1
Date: 21-Sep-2018
Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta
Checked By: Yogesh Jadhav
Approved By: Satish Kumar P
Page: 91 of 1052
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
DTC’s confirmation
(checks before handing over vehicle to customer)
:
4. Check the errors at Ignition ON, engine running @ Idle & Fly-up with different vehicle speeds also.
5. If error present, then rectify the errors.
6. Confirm that there is no error logged in EMS before handing over vehicle to customer.
Circuit Schematic:
Component Location & Image:-
NA
Connector View & Information: -
Power ground
Power supply
CAN_H
EMS ECU
RCM ECU
CAN_L
Ignition
