Description
Pin details
Gnd 1
Connector 1 pin 34
Gnd 2
Connector 1 pin 47
Gnd 3
Connector 4 pin 26
Batt 1
Connector 3 pin 2
Batt 2
Connector 3 pin 1
Batt 3
Connector 5 pin 1
Ignition
Connector 1 pin 9
CAN_H_Body
Connector 4 pin 12
CAN_L_Body
Connector 4 pin 13
CAN_H_Chasis
Connector 1 pin 48
CAN_L_Chasis
Connector 1 pin 49
