ENGINE 1.3 QUADRAJET (75PS)
16
To discharge the water do the follows :
1. With turned off engine, put a tube on the plastic
line (1) that jut s out the upper p art of the drain
device.
2. Partially unscrew, with an appropriate tool, the
discharge cock (2) Do not pull out the device from
here it is inserted.
3. Do a “key-on” without turning on the engine.This
is done to put the filter under pressure.
4. When the discharge is done, check that quantity
of discharged liquid is between 75cc and 80cc.
5. Close the device with appropriate torque as per
drawing.
