34. Remove the clamp and take out the pipe with

the air mass flow sensor connected to the

turbocharger.

35. Remove front two tyres.

36. Disconnect the left and right drive shafts from

the vehicle.

(For removal procedures refer

Transaxle section).

37. Use suitable belt/chain to fix a zip crane to the

engine lifting hooks located at front and rear

of the engine.

38. Raise the crane slightly up until very light

pressure is applied to the engine.

39. Loosen and remove the 2 mounting nuts and

one bolt on engine 'B' mount assembly.

40. Remove the mounting bolts of the “A” mount

assembly.

41. Loosen and remove the “C” mount assembly

mounting fasteners. Take out the mount

assembly.
