1.5L REVOTORQ ENGINE

106

C. EXHAUST ASSY. FRONT

REMOVAL

1. Remove the mounting bolt of the front end

exhaust pipe support clamp connecting to the

engine.

2. Remove the mounting nuts of the front

exhaust pipe connecting the catcon.

FITMENT

For fitment follow reverse procedure of removal.

NOTE



Use new gaskets every time while fitment

and tighten nuts and bolts to specified

torque.

D. CLOSED

COUPLED

CATALYTIC

CONVERTER

REMOVAL

1. Loosen and remove the mounting fasteners of

the exhaust front pipe to catcon.

2. Remove the mounting bolt of the catcon

support bracket mounted on the engine.
