1.5L REVOTORQ ENGINE
97
7. Raise the vehicle off the ground and remove
the engine shield guard.
(Refer Body section
for removal of engine shield guard).
8. Drain the engine oil by removing the drain
plug into a suitable container.
9. Drain the engine coolant by removing drain
plug into a suitable container.
10. Remove the drain plug from the transaxle.
Drain the transaxle oil from the vehicle.
11. Recover A/C compressed gas using suitable
recovery unit.
12. Disconnect the hoses and remove mounting
bolts of the auxiliary tank to take it out from
engine.
