TA65 Star AMT
22
9. Remove ball joint (steering rack) from steering
knuckle from RH & LH sides
10. Remove stub axle ball joint Mtg. & Remove
Lower Control Arm (LCA).
11. Drain the Transaxle oil from Drain plug as
shown below
12. Swing out both drive shafts from transaxle
and place it suitably alongside.
Do not pull drive shaft excessively as the
plunge joint will come out of housing and
damage the boot Pry. Plunge joint housing for
taking out joint out of splines. Do not place the
CV drive shaft on rough / uncleaned surfaces.
This might damage the drive shaft boot.
13. Disconnect Transmission arthing cable from
Gear Box.
14. Lower the car & support the Engine from
Bottom side.
15. Remove B-Mount Nut & Loosen B Mounting
stud as shown
16. Remove starter motor mounting Bolt.
