1.2L REVOTRON ENGINE
108
5. Remove the injector retainer on the fuel rail.
6. Remove the fuel injectors.
NOTE
Injector should be tagged as soon as it is
removed to avoid chances of it being
interchanged. Since the code of each
injector is calibrated to the EMS, whenever
an injector is replaced it codes of the
respective injectors should be fed in the
EMS ECU using diagnostic tool.
FITMENT
Follow the reverse order of removal for fitment.
Vacuum clean the injectors.
D. SPARK PLUG REMOVAL
1. Remove the battery negative terminal.
2. Remove air filter assembly.
3. Remove all the electrical connections.
4. Remove ignition coil from head cover by
removing its fasteners.
