1.2L REVOTRON ENGINE
104
22. To disconnect the exhaust front pipe loosen
the clamp near Catcon and remove the bolt
on the engine.
23. Disconnect the gear shift cable and selector
cable from the transaxle.
24. Disconnect the clutch cable connection from
the transaxle.
25. Disconnect suction and discharge hoses
connected to the compressor.
26. Remove front two tyres.
27. Disconnect the left and right drive shafts from
the vehicle.
28. Use suitable belt/chain to fix a zip crane to the
engine lifting hooks located at front and rear
of the engine.
29. Raise the crane slightly up until very light
pressure is applied to the engine.
30. Remove the mounting of the Engine 'B'
mounting bracket.
