BODY
19
driver side, remove two tree clips to flip
open the wheel arch carpet and expose the
earthing connections.
13.Disconnect the fuse box wiring harness
connections and remove the two mounting bolt
earthing connection.
passenger side, remove two tree clips to flip
open the wheel arch carpet and expose the
earthing connections.
15.Disconnect the BCM wiring harness
connections and remove the two mounting bolt
earthing connection.
16.Pry out the cap on the CCB mounting bolt
access on both sides of vehicle (LH side
illustrated).
17.Remove the CCB mounting bolts on LH and
RH side both.
