BODY
23
9.2.7 FRONT BUMPER
REMOVAL
1. Open the bonnet.
2. Loosen and remove the four mounting screws
along with the washers from the top side of the
bumper.
3. Remove two clip buttons from the bumper
which hold the head lamps.
4. Loosen the five mounting screws at the bottom
of the bumper.
5. Loosen and remove two mounting screws of
the outer liner from the inner side of wheel
arch. Follow the same procedure at the other
end also.
6. Pry out the front bumper from wheel arch end.
7. Disconnect fog lamp connectors and remove
the bumper.
FITMENT
For fitment follow the reverse procedure of
removal.
