972 / 1906
REAR SUSPENSION
16
2. Place the guide bush and mount the support
on the guide bush.
3.
Place the upper link guide bush housing on to
the support.
4. Mount the bush over the housing.
5. Place the Drift
above the bush and press it
using Press machine.
II. LOWER LINK BUSH REMOVAL
1. Remove the Lower link bush using special tool
assembly
(Part No.2870 5890 01 04).
as show
in below arrangement.
2. Place the lower link
bush housing on to the
support
(1)
3. Place the drift
(2)
above the housing and press
the same onto the press machine and take out
the bush.
