REAR SUSPENSION
19
IV REAR DAMPER BOTTOM BUSH.
REMOVAL
1. Remove the shock absorber bush using
special tool assembly
(Part No.
2870 5890 32
58).
as shown in below arrangement.
2. Place the lower bush of damper on bottom
support.
4. Place the dolly above and press the same
using press machine to push out the bush from
damper bush housing.
INSTALLATION
1. Install the damper bush using special tool
assembly
(Part No. 2870 5890 32 58).
as
shown in below arrangement.
2. Place the lower bush with spacer on damper
support.
3. Place the dolly above and press the same
using press machine to push the bush inside
damper as shown in below fig.
