HEXA

GEAR BOX

8. Take out the reverse block assembly from the top

cover.

9. Dismantle the reverse block assembly by remov-

ing the pin from the reverse blocker and take out

the reverse blocker spring.

INSPECTION



Check the top cover housing assembly for cracks.



Check the condition of spiral pin

ASSEMBLY

For fitment follow reverse procedure of removal.

NOTE



For fitment of oil seal use suitable drift.



Fill 3% grease MoS2 320 in the pocket between

main lip and dust lip of oil seal.

REAR COVER (4X2)

DISMANTLING

1. Remove the main shaft oil seal from rear cover

with the help of suitable drift.

2. Loosen and remove the adaptor.

3. Remove the oil seal of speedo shaft (if fitted).
