PIN
DESCRIPTION
B1
SENSOR 8
B2
SENSOR 9
B3
NC
B4
NC
B5
USENS
B6
SENSOR 10
B7
SENSOR 11
B8
GND SENSOR
16.Physical Images
PDC ECU front view:
PDC ECU component connector side view:
PDC Ultrasonic Sensor View:
