HEXA

ELECTRICAL

286

Warning

If the low oil pressure indicator does not glow or

remains ‘ON’ with the ‘IGN’ ‘ON’ and engine is

running, it indicates a fault in the electrical circuit /

lubrication system. Take your car to a TATA

Authorized Service Centre.

2.9.10 Low Fuel Indicator

This symbol lights up when ignition is turned ‘ON’.

The symbol lights up continuously if fuel level in

the tank is low. Fuel needs to be filled

immediately.

It shall blink if there is any fault in the system.

Take your car to the nearest Tata authorized

service station.

2.9.11 High Temperature Warning

This symbol lights up when the ignition is turned

‘ON’ and goes ‘OFF’ in approx. 4 sec.

If the engine is overheating, this indicator blinks

along with an audible buzzer at this stage, take

the car to the nearest authorized Service outlet.

This symbol blinks and audible buzzer sounds

simultaneously when engine coolant temperature

is more than normal.

When engine coolant temp increases to

hazardous level, telltale shall blink with RED color

and it is accompanied by audio warning.

Warning

Never remove the radiator pressure cap from the

radiator when the engine is hot. Do not restart the

engine until the problem has been duly attended.

2.9.12 Water in fuel indicator

This symbol indicates excess water accumulation

in the sedimenter. It shall come ‘ON’ when Ignition

is turned ‘ON’ and shall go ‘OFF’ in approx. 3

seconds. When this lamp blinks along with chime

take the car to the nearest authorized Service

center.

20.9.13 ABS Indicator

When Ignition is turned ‘ON’, this symbol comes

‘ON’ for 4 seconds and goes ‘OFF’.

This symbol shall continue to remain 'ON' if there

is a problem in the ABS system.

Note

If the warning is continuously ON Take your Car

to TATA authorized service center.

2.9.14 Airbag Indicator

The air bag warning symbol comes on for

approximately 4 seconds when the ignition is

turned ‘ON’ and goes ‘OFF’.

Note

If the warning is remain ‘ON’ or blinks, take your

car to the Tata Authorized Service Centre.

2.9.15 Seat Belt Indicator

Seat belt warning indicator comes ‘ON’ for 4

seconds, when ignition is turned ‘ON’.

Lamp shall be made ON continuously for 30 sec if

seat belt is not fastened.

If seat belt is not fastened, the lamp will be ‘ON’

continuously without audio alarm till vehicle speed

reaches 16 km/h.

When vehicle speed exceeds above 16 km/h, the

lamp will continue to flash with intermittent audio

alarm.

Once the seat belt is fastened, the buzzer and

warning indicator shall go ‘OFF’.

2.9.16 Immobilizer Warning Indicator

This symbol is of a system that disables engine

starting if you do not use the original key. The

user has to use original key for authentication and

unlocking the car. Refer to Immobilizer section for

details.
