HEXA

ELECTRICAL

INSPECTION:

1. Check the filaments in the bulb if blown replace

the faulty bulb.

2. Check for damages in the locks area.

REFITMENT:

1. Connect the electrical connection.

2. Fit the roof lamp into cutout provided on roof

console. (

snap fitted

)

8.4.7 THIRD ROOF LAMP

Third roof lamp is fitted with a three-way switch.

Switch has ON, OFF and DOOR positions. In the

ON or OFF position, the lamp is directly controlled

by the switch. In ON or OFF position, no lamp

dimming is used.

In the DOOR position, the lamp operation is

controlled directly by the BCM. It consists of LEDs.

REMOVAL:

1. Pry out the roof lamp assembly from the rear

roof console.

2. Disconnect the electrical connection.

3. Take out the lamp.

REFITMENT:

1. Connect the electrical connection.

2. Fit the roof lamp into cutout provided on rear

roof console. (

snap fitted

)
